5FR - Frame

Ecrane cu rama vizibil de la 1,6 la 4 m lăţime

5FR - Frame - Ratio 1:1 Dimensiune ecran ....... Greutate160 x h 160 cm .................. 8 kg180 x h 180 cm .................. 9 kg200 x h 200 cm ................ 10 kg250 x h 250 cm ................ 13 kg300 x h 300 cm ................ 16 kgDimensiune rama = dimensiune ecran + 16 cm
Vezi toate
5FR - Frame - Ratio 4:3 Dimensiune ecran ....... Greutate160 x h 120 cm .................. 8 kg180 x h 135 cm .................. 9 kg200 x h 150 cm ................ 10 kg220 x h 165 cm ................ 11 kg250 x h 190 cm ................ 13 kg300 x h 225 cm ................ 17 kg350 x h 265 cm ................ 21 kg400 x h 300 cm ................ 25 kgDimensiune rama = dimensiune ecran + 16 cm
5FR - Frame - Ratio 16:9 Dimensiune ecran ....... Greutate160 x h . 90 cm .................. 8 kg180 x h 101 cm .................. 9 kg200 x h 112 cm ................ 10 kg220 x h 124 cm ................ 11 kg250 x h 140 cm ................ 13 kg300 x h 169 cm ................ 17 kg350 x h 197 cm ................ 21 kg400 x h 225 cm ................ 25 kgDimensiune rama = dimensiune ecran + 16 cm

Componente 1 - Plastic angular junction (up to 300 cm width only)2 - Frame made of matte black enameled aluminum3 - Sliding link for rubber band4 - Sliding bracket (already fixed to the frame)5 - Bolts for brackets (already fixed to the frame)6 - Eyelet7 - Rod made of galvanized metal8 - Rubber band
Fixarea ecranului a - Frame made of matte black enameled aluminumb - Sliding link for rubber bandc - Eyeletd - Rod made of galvanized metale - Rubber band
Optionals 5FR∙S1 - Couple of tripodsTo be fixed to the frame at a point no lower than the center of the screen.Tripods excursion:- minimum 117 cm- maximum 205 cmWeight: 7,5 kg each
5FR - Frame is a frame screen up to 4 m wide.
It can be hung or supported by two special floor stands.
Structure
sectional matte negru enameled din aluminiu 80 x 20 mm
Ecran
at choice - conform Normei Europene EN 13501·1
Suduri fără suprapozare
Fixing of the ecran
with rods și elastics
Instalare
to ceiling / to wall
couple of tripods for floor (optional)
Caracteristici
simplicity of assemblage și transport

Graficul de culoare

Ecrane pentru proiecţie faţă PBO - Bianco OtticoPBL-BlackoutPBM-BlackoutMicroforatoPST-Stormy
Ecrane retroproiecţie RNV - NevadaRAR-Arizona
