QPE - Heavy PVC for outdoor use



QPE - Heavy PVCIn the picture: the colour 411 dark yellowPVC film is thick and resistant on cloth support, for very effective waterproof coverings.The PVC coating on both sides of the support fabric high tenacity polyester, it is smoother and shiny on one side and slightly less shiny and with the weft slightly more in evidence on the other.
View all
QPE - Heavy PVC421 orangeIn evidence the supporting fabric made of polyester.
The installation of a Scenografic basin realized with the color 412 light blue. RAI, ''Games without Frontiers''
The installation of a Scenografic basin realized with the color 412 light blue. RAI, ''Games without Frontiers''
A Scenografic basin used to realize an marsh on a stage. Teatro Lirico, ''The Oprichnik''
The QPE - Heavy PVC is often used for waterproof protective coverings too.The coverings are custom realized, in large size (tents of circus, etc.) or in small-size like those that are protecting the circles in the picture. In that case it was used the color 427 black. Winter Olympics Turin 2006
Another view of the circles protected by custom coverings made of the color 427 black. Winter Olympics Turin 2006
QPE - Heavy PVCIn the picture: the colour 411 dark yellowPVC film is thick and resistant on cloth support, for very effective waterproof coverings.The PVC coating on both sides of the support fabric high tenacity polyester, it is smoother and shiny on one side and slightly less shiny and with the weft slightly more in evidence on the other.
Composition
PVC coating (73% on its total weight) on a supporting high tenacity polyester fabric (27% on total weight)
Weight
720 g/m² ± 5%
Ignifugation
flame retardant C2 / M2 / BS7837:1996
Thickness
550 μ ± 5%
Width
250 cm
Roll length
60 m
Packing method
rolled
Colors
14 colours
Face/reverse

Features
high resistance to tensile stress and to laceration
complete impermeability
Weldability
Rating 5.0 - Welding with superposition only of ± 2 cm

Available in
only in custom realizations (backdrops, stage pools, etc.)

Colour chart

QPE - Heavy PVC410. white414. cream419. beige420. yellow411. dark yellow421. orange422. red
QPE - Heavy PVC415. light grey423. gray417. dark grey418. brown
412. light blue413. blue425. dark blue424. turquoise426. light green78. green432. dark green427. black
